WES 125 without support
Turnstile for dowelling or setting in concrete
- Horizontally rotating, all 90° lockable
- All steel components hot-dip galvanized
- Rotating support made of steel tube 121.0 x 4.0 mm
- Main support made of steel tube 101.6 x 2.9 mm
- One-piece aluminum barrier beam 86 x 46 mm, with anti-seat protection and sign / advertising baffle
- From 2500 mm with cable reinforcement
- Without support (only as accessories)
- Mounting by screwing on the floor plates 250 x 250 mm or setting the mounting cage in concrete
- Height above ground 1000 mm
- Various locking options on the main support, in standard for padlock
Impressions
Dimensions & Order No.
| Length | Article no. (dowelled on) | Article no. (set in concrete) |
|---|---|---|
| 1,5 m | 3-125-1500-0003 | 3-125-1500-0027 |
| 2,0 m | 3-125-2000-0006 | 3-125-2000-0023 |
| 2,5 m | 3-125-2500-0002 | 3-125-2500-0013 |
| 3,0 m | 3-125-3000-0005 | 3-125-3000-0025 |
| 3,5 m | 3-125-3500-0005 | 3-125-3500-0019 |
| 4,0 m | 3-125-4000-0007 | 3-125-4000-0017 |
| 4,5 m | 3-125-4500-0002 | 3-125-4500-0018 |
| 5,0 m | 3-125-5000-0010 | 3-125-5000-0026 |
| 5,5 m | 3-125-5500-0008 | 3-125-5500-0014 |
Accessories
- Lock case profile cylinder for: turnstiles and height limitation and WES 31 and WES 41
- Lock case profile cylinder and fire brigade triangle for: turnstiles and height limitation and WES 31 and WES 41
- Extension set forced closing for turnstile and height limitation (only in combination with lock case)
- Support for lock case Fire brigade triangle for vertical turnstiles
- Lock case support profile cylinder lock for vertical swing locks
- Extension set triangular lock Simplex for turnstile and height limitation
- Fire brigade triangular key standard
- Padlock 60 mm
